Freeman 22 MK2
An upgrade of the original Freeman 22 Mk1, the cabin is full height throughout with the distinctive step in the side deck.
Mr Freeman's second production model was also 22 feet long and became known as the Freeman 22 Mk2 to differentiate the models.
Specification
This is a factory specification from the original boat brochures. It must be noted that each boat was individually made, sometimes to owners particular specifications and the manufacturing process developed over time.
| Length: | | 22' | | Beam: | | 7' 6" | | Draft: | | 2' | | Headroom: | | 5' 10" | | Weight: | | 26 cwts | | Speed: | | 8 - 9 knots | | Construction: | | Fibreglass | | Berths: | | 4 | | Water Capacity: | | 15 Gallons | | Fuel Capacity: | | 15 Gallons | | Start Date: | | 1964 | | End Date: | | 1970 |
Original Engine(s)
The boats were fitted with a number of engine options from new.
This model could of been fitted with one of the following engines depending on the original order.
Example Engines
WaterMota Sea Wolf Pre Crossflow upto 1968, WaterMota Crossflow from 1968 with J-Type Gearbox, Perkins 4.107
Further information on the engines and the models they were fitted in can be found in the engines section.
|
